Loading grid - infiltration grid

Inquire about this product

Length: 800 mm
Width: 600 mm
Height: 43 mm
Weight: 11 kg
Mark: 103R
Number of pieces per pallet: 60
Footprint: 760 x 560 mm (mat has locks)
Inquire about a product

Sustainable Solution for Parking Areas, Service Zones, and Industrial Surfaces

Looking to create a parking area that’s both durable and water-permeable? Our heavy-duty infiltration grids offer a reliable solution that combines functionality, sustainability, and long service life. They’re ideal for reinforcing surfaces where maintaining the natural rainwater runoff is essential.

As an environmentally friendly alternative to asphalt or concrete, this system allows on-site water infiltration, unlike traditional impermeable surfaces.

Heavy-duty infiltration grids can be used not only as a final surface layer, but also as part of the substructure to reinforce soft or waterlogged ground. They’re particularly useful where surface stability is needed without compromising the natural appearance of the environment.

Where can infiltration grids be used?

  • Parking areas for homes, businesses, and public buildings

  • Handling zones and parking bays

  • Industrial and logistics areas

  • Driveways and access roads with load-bearing requirements

  • Functional slope and riverbank reinforcement

  • Events and temporary construction sites

  • Erosion control

Suitable surface finishes:

  • Filled with crushed gravel, pebbles, or screenings

  • Grass-filled – used as a traditional eco-grid (grass paver)

The infiltration grid system can also be combined with our flooring panels (codes 102 and 103) to create versatile, multi-purpose surfaces.

  • load capacity 3.5 t / 1 dm²
  • chemically stable
  • fire resistant
  • fast assembly and disassembly
  • can be combined with heavy-duty floor panels (code 102 and 103)
